Multifunctional Two Stage Nitrogen Compression Skid 2000Nm3/H For High Final Discharge

Name: Multifunctional Two Stage Nitrogen Compression Skid 2000Nm3H For High Final Discharge
Brand: Zhong Rui Wei Fei
Price: 1 USD

Best Multifunctional Two Stage Nitrogen Compression Skid 2000Nm3/H For High Final Discharge wholesale

Price : US $9999

Production Rate : 2000Nm3/h

Technology : Pressure Swing Adsorbtion (PSA)

Function : Nitrogen pressurization

Key Selling Points : Multifunctional

Color : Yellow

After-sales Service Provided : Service Machinery Overseas

Place of Origin : Shandong, China

Warranty : 1 Year

Application : Boosting module

Machinery Test Report : Provided

Product name : Nitrogen or Natural gas

Dimension(L*W*H) : custom

Video outgoing-inspection : Provided

MOQ : 1 Set

Weight : 39000 KG

Inlet pressure : 15barg

Core Components : Skid Main configurations: Explosion-proof motor, A

Delivery Pressure : ≤70MPa

Brand Name : Zhong Rui Wei Fei

Voltage : Consult customer service

MOQ : 1 set

Usage : Natural Gas/Nitrogen

Capacity : 2000Nm3/h

Contact Now

Products Description

Multifunctional Two Stage Nitrogen Compression Skid 2000Nm3/H For High Final Discharge

The nitrogen pressurization pry device is a complete and independent pressurization module that integrates all necessary components such as a nitrogen booster, pipeline system, valves, instruments, and control unit, and is fixed on a steel structure base (pry block). Its core function is to pressurize low-pressure nitrogen gas from upstream sources (such as PSA nitrogen generators or low-pressure storage tanks) to the required high-pressure state for the process or application.

Working principle Intake: Low pressure nitrogen gas (usually 0.5-1.0 MPa) enters the turbocharger through an inlet filter. Compression: The booster compresses nitrogen, increasing pressure and temperature. Cooling and Separation: High temperature and high-pressure nitrogen gas is cooled by an aftercooler and then removed from the condensate by a gas-liquid separator. Output: Clean high-pressure nitrogen gas (pressure can reach 15-45 MPa, or even higher) is transported to the point of use through the outlet pipeline. Control: PLC automatically controls the start and stop of the booster according to the set value of the outlet pressure, maintaining stable outlet pressure. Stop the machine when the pressure reaches the set upper limit, and automatically start when the pressure drops to the set lower limit.

Medium	Nitrogen or Natural gas
Rated Flow	2000Nm3／h
Inlet pressure	15barg
Delivery Pressure	≤70MPa
Weight	39000kg
Inlet Temperature	≤ambient temperature+15℃
Dis. Temperature	≤ambient temperature+15℃
Dim.(L×W×H)	10600×3100×2800mm
Installing Form	Skid Main configurations: Explosion-proof motor, Ariel booster compressor, air cooler, liquid-gas separator, etc. The equipment is suitable for the requirements of drillig, downhole special operations, gas lift drainage, pipeline purging, and energy enhancement during the development of natural gas and petroleum.

Product display

Modularization and Integration: All components are pre installed and tested in the factory, and delivered as a whole, significantly reducing on-site installation workload, time, and cost. Compact and space saving: The optimized design of the pry mounting structure is very compact, especially suitable for space limited occasions such as offshore platforms and ship engine rooms. High reliability and safety: The integrated design and strict control logic are equipped with multiple safety interlock protections to ensure stable and safe operation of the device. Plug and play: After arriving at the site, simply connect the power supply, inlet low-voltage pipeline, and outlet high-voltage pipeline to quickly put it into operation. Easy to maintain: Centralized layout of components, clear maintenance channels, convenient for daily inspection and maintenance. Quality controllable: Integration and testing are completed in a controlled factory environment, with quality far superior to on-site decentralized installation.

Product application areas

This device is widely used in situations that require high-pressure nitrogen gas: Ship and Ocean Engineering: Provide power nitrogen for high-pressure fire protection systems, conduct high-pressure purging and air tightness tests on pipelines and containers. Provide high-pressure inert gas replenishment for the cargo hold of chemical tankers/oil tankers. Petrochemical industry: Nitrogen purging, replacement, and pressure testing of pipelines and reactors. Tank sealing and instrument air system. As a power source for pneumatic valves. Aerospace: Fill the aircraft tires and landing gear with nitrogen. Boosting and testing of rocket fuel systems. Power industry: Used for protection, purging, and power in nuclear and thermal power plants. Other industries: Auxiliary gas pressurization for laser cutting machines, packaging for the food and beverage industry, etc.

Packaging and shipping

Wooden packing box is used for packaging, with anti-collision foam blocks inside, and the packaging method meets the export standard. Some important vulnerable components in the equipment will be treated separately to prevent collisions

Our company

Qingdao Zhongrui Weifei Marine Equipment Co., Ltd., founded in 2019 in Qingdao West Coast New Area, is a joint - venture of Ruiyuan Holdings Group and Kerui Group with a 300 - million - yuan registered capital. As a national high - tech entity, it masters the full value chain of marine oil and gas equipment, from R&D to after - sales service. Specializing in high - end intelligent oil and gas equipment for marine and underwater use, its main products include automated drilling and repair gear, production - enhancing equipment, ship - based nitrogen producers, and underwater wellhead Christmas tree support. Guided by the quality policy of "Pursuing Excellence, etc." and business philosophy of "Integrity, etc.", it is making strides towards its goal of making marine oil and gas equipment safer and more intelligent.

Why Choose Us

We are one of the leading manufacturers globally and possess extensive experience. Our product range is highly flexible and we are constantly expanding it to meet the demands of our customers.

FAQ

Q1: Are you a trading company or manufacturer? A: Firstly. we are a manufacturer, we have our own factory and engineers. Secondly, we have our own international trade teams to provide services for you. Thirdly, we provide the lifetime technology support and the best after-sale service. Q2: What is your term of payment? A: 30%T/T in advance and balance before shipment. 30% T/T in advance and Irrevocable L/C at Sight. Q3 How long is your delivery time? A: Depending on what type of machine you are purchased. Q4: What is your product quality assurance policy? A: We offer a warranty period of 1 year, free lifetime technology support. Q5: Do you offer OEM/ODM service? A: Yes, please let's know your specific require. Our engineer will follow your requirement to design for you and provide detailed technical specification and commercial quotation. Q6: Does your product used or new? RTS product or customized product? A:Our machine is new unit, and following your specific require to design and make it.
